Oxygen Generator

High quality professional customized PSA molecular sieve oxygen, medical oxygen generator, oxygen refueling station, pressurization and decompression device with purity 99.5% are produced by our compamy, Ningbo Qingjie Medical Devices Co.,Ltd.. And it can be purified. Oxygen booster unit can be connected to the reloading cylinder device!

Send Inquiry

Product Description

Master List of Oxygen Generator

Model number	Oxygen yield(m3/h)	Purity(%)	0xygen outlet pressure(Mpa)	Installed power (KW)	Weight KG(Including air compressor without oxygen tank)	External dimensions(mm) without oxygen tanks
WECLEAR-PSA-002	2m3/H	93±3	0.2-0.8	4	620	13008651800
WECLEAR-PSA-003	3m3/H	93±3	0.2-0.8	6.5	950	32009801800
WECLEAR-PSA-005	5m3/H	93±3	0.2-0.8	8.5	1250	350010001800
WECLEAR-PSA-010	10m3/H	93±3	0.2-0.8	16.5	1730	370014802200
WECLEAR-PSA-015	15m3/H	93±3	0.2-0.8	20	2060	400015002400
WECLEAR-PSA-020	20m3/H	93±3	0.2-0.8	24	2560	530015102300
WECLEAR-PSA-025	25m3/H	93±3	0.2-0.8	32	3370	530018502100
WECLEAR-PSA-030	30m3/H	93±3	0.2-0.8	39	3450	550019002600
WECLEAR-PSA-035	35m3/H	93±3	0.2-0.8	39	3750	550019002600
WECLEAR-PSA-040	40m3/H	93±3	0.2-0.8	47.5	4200	600020002800
WECLEAR-PSA-045	45m3/H	93±3	0.2-0.8	47.5	4700	650021002800
WECLEAR-PSA-050	50m3/H	93±3	0.2-0.8	57.5	5400	700022002800
····	Please consult us for 50-500m3 or more!					····
